Cove Perfekt Ceiling
by Axis Lighting
Lighting Distribution
Indirect, Asymmetric Indirect
Output
Up to 1300 lm/ft
Efficacy
Up to 119 lm/W
Segments
2’ to 12’ (1’ increments)
Specsheets
CCT
2700K , 3000K , 3500K , 4000K
CRI
80.0, 90.0
Color / Finish
Black , Custom , White
Controls Options
Daylight Sensor , Occupancy Sensor
Dimming Protocol
Lutron
Dimming Range
1% , 5% , 50%
Dynamic LED Color
BIOS SkyBlue , Tunable White
Efficacy
81, 84, 85, 89
Lamp Life
50000
Lamp Source
LED
Listings
CSA , UL
Materials
Aluminum , PMMA , Steel
Mounting
Arm , Cable , Ceiling , Corner , Cove , Grid , Plenum , Stem , Suspended , Wall
Ratings & Compliance
Chicago Plenum , Damp , Dry , IC Rated , IP65 , Made in Canada
Static LED Color
BIOS Static , Blue , Red , White
Voltage
120 V , 277 V , 347 V , UNV
Warranty
5 yr
Watts
0.6, 3.5, 6.0, 7.9
Watts / Linear Ft.
6.0, 7.9, 10.6, 10.6, 13.5
